Digital SLR Camera adapters for Nikon /Canon /Olympus cameras and Meiji Techno Microscopes

35mm SLR Camera Adapters For Microscopes Capturing video or photographic images through Meiji Techno microscopes is a very common and relatively straightforward practice. Nearly all Meiji Techno microscopes are available in trinocular models designed for just this purpose. The components listed below will allow you to mount your 35mm film or digital SLR camera on any of our trinocular model microscopes. Those of you using digital SLR’s, you’ll find the adapters listed below on this page. 35mm Photomicroscopy You will need three components to attach a 35mm camera body onto a trinocular tube: 1) The appropriate T-2 adapter ring for your SLR camera body: T2-1 T2-3 T2-5 T2-7 T2-9 Canon Pentax K Nikon Contax, Yashica Canon EOS T2-2 T2-4 T2-6 T2-8 T2-10 Minolta Pentax S (threaded) Olympus Konica Minolta Alpha/Maxim 2000 T-2 Adapter The T2 adapter rings attach directly to your camera body’s lens mount. 2) A photo eyepiece, available in the following magnifications: MA986 MA512 MA500  MA508 1.9x magnification 2.5x magnification 3.3x magnification (with reticle mount) 5x magnification Photo Eyepiece Photo eyepieces perform the same function as the standard 35mm camera lens (i.e. focusing the image at the plane of the film). 3) One of two MA150 series camera attachments: MA150/50 MA150/60 Straight-tube camera attachment Camera attachment with built-in focusing eyepiece These are used to mount the camera assembly onto the trinocular tube of the microscope. MA150/50 on EMZ-5TR MA150/60 on EMZ-5TR
